Xbox Series X or Xbox One disc drive making a loud grinding or clicking noise, slipping when taking discs, or stuck with a jammed game disc? Mechanical gear alignment, roller restoration & console repair at PRC Sydney.
What Causes Loud Grinding, Buzzing & Clicking Inside an Xbox Series X or Xbox One Disc Drive?
The slot-loading optical drive inside the Xbox Series X and Xbox One series uses a precision-timed sequence of optical infrared slot sensors, counter-rotating rubber intake rollers, nylon cam sliders, and a magnetic top spindle clamp. The moment you slide the edge of a Blu-ray disc through the front felt dust curtains, the loading motor engages to pull the disc inward and simultaneously raise the laser sled and magnetic hub clamp.
Across hundreds of consoles serviced by the PRC Workshop Laboratory Team (with 18+ years of experience in Sydney), three mechanical faults cause loud grinding or jammed discs:
- 1. Out-of-Sync Clamping Cam Gears (Loud Machine-Gun Grinding): If a disc is pushed in forcefully by hand while the drive is halfway through an eject cycle, or if the console is knocked while a disc is spinning, the white nylon side-rail sliders jump a tooth on the loading pinion gear. The loading motor continues spinning against the jammed plastic stop, producing a loud ratcheting sound.
- 2. Glazed Rubber Intake Feed Rollers (Disc Slips Halfway In or Out): Fine dust from the front intake vents coats the two rubber pinch rollers right behind the slot. The motor whirs, but the rollers slip harmlessly against the slick polycarbonate edge of the disc.
- 3. Dry Laser Worm-Screw Rail or Foreign Object Obstruction: When the steel guide rods and brass worm-screw that move the optical laser sled dry out, the stepper motor skips steps with a rapid clicking sound, or coins/cards inserted by children jam the spindle lift table.
Console Lab Triage: Stuck Game Disc & Grinding Noise on Eject
Customer (Mount Druitt):
Hi team, my son's Call of Duty disc is stuck inside his Xbox Series X. When I press the eject button it beeps and makes a horrible plastic grinding sound for three seconds, then pulls the disc back in. Can you get the disc out and fix the drive at St Marys?
PRC Workshop Laboratory Team (St Marys):
Yes, do not try to pull the disc out with tweezers or pliers as that scratches the data layer of your game and bends the top magnetic clamp! Bring the Xbox straight to our standalone workshop at 122 Queen St, St Marys (5 minutes from Mount Druitt) or drop it off 7 days at Schofields Village. We disassemble the optical drive shell, recover your game disc unharmed, clean and re-condition the rubber feed rollers, and realign the nylon cam gears while keeping your original married drive daughterboard intact.
How to Safely Eject a Stuck Disc Using Microsoft's Manual Eject Pinhole
If you urgently need to retrieve a borrowed game disc before bringing your Xbox into our St Marys laboratory, Microsoft built a mechanical manual release lever into the chassis:
- 1. Unplug the Mains Power Cord Completely: Never insert a metal clip into the console while 240V AC power is connected.
- 2. Locate the Manual Eject Hole: On the Xbox Series X, the manual eject hole is located inside a specific circular hole on the bottom plastic base foot (under the optical drive corner). On the Xbox One X and Xbox One S, it is located on the left side panel directly beside the yellowing warranty sticker / USB port.
- 3. Press Straight In With a Large Unbent Paperclip: Pushing firmly against the internal spring lever manually lowers the laser sled and nudges the disc 15mm out of the slot so you can grasp it by the edges. If the paperclip hits a solid blockage, stop immediately and bring the console to our bench.
Inside Our St Marys Mechanical Drive & Roller Restoration
Rather than replacing your entire drive with an unpaired unit that would trigger an E100 firmware brick, our technicians open the metal DG-6M5S / DG-6M1S drive housing, ultrasonically clean and rubber-rejuvenate the dual intake rollers, synchronize the left and right nylon cam tracks, apply white lithium grease to the worm gear rails, and gently clean the 405nm Blu-ray lens.
Verbatim PRC Xbox Hardware, Thermal & Controller Pricing Table
Check our complete verbatim pricing below, or visit our Xbox Repair Sydney Hub, Xbox Console Directory, and PS5 Disc Drive & HDMI Lab:
| Console Model Family | Verbatim Backend Service Tier | Workshop Price | Warranty & Lab Scope |
|---|---|---|---|
| Xbox Series X | S 2020 & Xbox One Series | Cleaning Service | $66 | 3-Month Warranty | St Marys Same-Day Fix |
| Xbox Series X | S 2020 | Cleaning Service with Liquid Coolant Replacement / Cooling Fan | $99 / $129 | 3-Month Warranty | St Marys Same-Day Fix |
| Xbox Series X | S 2020 / Xbox One Series | Power Supply Replacement | $149 / $150 | 3-Month Warranty | St Marys Same-Day Fix |
| Xbox Series X | S 2020 / Xbox One Series | Controller Repair (One Joystick / Both Joystick Stick Drift Fix) | $39 & $55 / $29 & $49 | 3-Month Warranty | St Marys Same-Day Fix |
Frequently Asked Technical Questions
Why do I have to tap or tilt my Xbox Series X or Xbox One just to get it to read or pull in a disc?
When the dual rubber feed rollers inside the slot become coated in household dust, they lose friction and cannot pull the disc fully onto the magnetic spindle hub. Tapping the console momentarily jars the clamping arm into place, but eventually knocks the plastic cam gears out of alignment.
What happens if a child pushes two discs or a coin into the Xbox Series X disc slot?
Forcing a second disc or foreign object into the slot pops the white nylon timing sliders off their guide tracks. Never pry inside the slot with a knife; our St Marys technicians open the top cover of the drive, extract the object safely, and reset the mechanical gear timing.
