PS5 HDMI Port Replacement & Micro-Soldering Sydney (September 2026)
PS5 HDMI port pins crushed, console shows white light but no TV signal? Phone Repair Centre provides same-day micro-soldered 4K 120Hz HDMI port replacement in Sydney.
"ps5 hdmi port replacement cost crushed bent pins white light no signal fix sydney"
Our technical team receives this exact question multiple times weekly. Here is our direct, transparent answer and cost breakdown for Sydney device owners.
Quick Answer: What Does It Cost to Fix?
PS5 white light of death, bent pins, or no signal on TV? Phone Repair Centre micro-solders upgraded reinforced PS5 HDMI 2.1 ports for $139 inc. GST, and replaces blown HDMI retimer IC chips for $169 inc. GST express in 2-3 hours at our St Marys lab.
Disclaimer: Component pricing fluctuates over time with wholesale supply. These estimates reflect active rates in September 2026. Contact our team for today's live price.
PS5 Models: CFI-1002A, CFI-1102A, CFI-1202A (Original), and CFI-2002A (Slim) found on base sticker. Also covers Xbox Series X Model 1882.
Repair Options & Official Pricing (GST Inclusive)
Upgraded Reinforced HDMI 2.1 Port
- Micro-soldering of all 19 HDMI pins with leaded solder
- Reinforced through-hole ground anchors for durability
- 2-3 hours express turnaround at St Marys workshop
Panasonic MN864739 BGA Replacement
- Precision hot-air micro-soldering of blown HDMI retimer chip
- Fixes white light of death (WLOD) with no TV display
- Full multi-stage 4K HDR 120Hz bench test
HDMI Port + Internal Dust Clean
- Includes new HDMI port plus full internal heatsink clean
- Complete protection against future thermal shutdowns
- 6-month warranty on all parts and labor
Technical Hardware Specifications & Repair Parameters
| Port Specification | HDMI 2.1 (supports 4K 120Hz, 8K 60Hz, VRR, ALLM, eARC) |
| Pin Architecture | 19 signal pins (through-hole and surface mount) + 4 reinforced chassis ground lugs |
| Video Chipset | Panasonic MN864739 HDMI video management transmitter IC |
| Console Behavior | Blue light pulses, transitions to solid white light, TV reports 'No Signal' |
| Supported Models | PS5 CFI-1002A, CFI-1102A, CFI-1202A, and PS5 Slim CFI-2002A |
| Turnaround Time | Same-day express service (1 to 2 hours) at St Marys & Schofields |
5 Signs Your Device Needs This Repair
- •('Console Shows White Light But No TV Signal', "Power light turns from blue to solid white, but TV screen remains black with 'No Signal'.")
- •('Pins Crushed or Pushed Inside Port', 'Looking into the HDMI port reveals twisted, flattened, or pushed-back gold contact pins.')
- •('Wiggling Cable Makes Video Flicker', 'Video only appears intermittently when applying heavy downward pressure on the HDMI cord.')
- •('Flickering Dots or Black Screen Dropouts', 'Screen flashes black for 2 seconds during gameplay due to fractured HDMI clock pins.')
- •("HDMI Cable Plug Won't Go In", 'Damaged internal plastic spacer prevents HDMI cable from plugging in all the way.')
How Our Technicians Complete Your Repair
Chassis Teardown & APU Shielding
We dismantle the console casing and extract the motherboard, placing kapton tape over surrounding SMD filters.
Infrared Pre-Heating & Hot-Air Desoldering
Bottom pre-heating to 180C allows gentle hot-air desoldering of the damaged port without lifting motherboard copper pads.
Pad Reconstruction & Reinforced Port Soldering
Anchor pads are cleared with copper wick, the new reinforced HDMI 2.1 port is soldered, and all 19 pins are verified individually.
4K 120Hz Gaming Stress Benchmark
The console is re-assembled with fresh thermal barrier paste and benchmarked on 4K 120Hz displays for 30 minutes.
Repair vs Buying New: Economic Breakdown
| Factor | Phone Repair Centre | Buying New Retail |
|---|---|---|
| Massive Financial Savings | Fixing the port for $139 completely restores your $799 PlayStation 5 console to perfect health. | Scrapping a working console over a damaged physical connector is a terrible financial loss. |
| Reinforced Durability | Our upgraded replacement ports feature thicker steel ground lugs that resist cable strain better than factory ports. | Continuing to wiggle broken cables risks shorting the 5V line and frying the main video IC. |
| 100% Data Preservation | All your saved game data, installed games, user profiles, and screenshots remain completely intact. | Sony service exchanges wipe console memory as part of their factory refurb process. |
Same-Day 1-2 Hour Express PS5 HDMI Port Replacement
Crushed HDMI pins holding you back from gaming? Bring your PlayStation 5 console into Phone Repair Centre at St Marys or Schofields for master-level micro-soldered HDMI port replacement.
Express Phone Repair & Protective Accessories Near Me: Western Sydney & North West Sydney
Looking for fast, walk-in phone repairs or durable device protection near Sydney & Surrounding Suburbs? Phone Repair Centre operates two dedicated Sydney locations: our flagship diagnostic laboratory at 122 Queen Street, St Marys, and our express kiosk at Schofields Village. We combine 30-minute hardware fixes with complimentary bubble-free screen protector application and premium mobile accessories in stock every day.
Express Walk-in Repairs (30 to 45 Mins)
- Screen & OLED Replacement: iPhone, Samsung Galaxy, Google Pixel, and iPad display renewals with True Tone preservation.
- Battery Renewal: High-capacity replacement cells installed same-day with store warranty.
- Charging Port & Audio Fixes: USB-C and Lightning port cleaning, debris removal, or micro-soldering replacement.
- Laser Back Glass Repair: Clean rear glass replacement with factory-tight seal alignment.
- Strict Zero Data Loss: Your photos, banking apps, and personal data stay untouched throughout the repair.
In-Store Protection & Accessories
- Free Screen Protector Fitting: 9H tempered glass, anti-peeping privacy protectors, and hydrogel films applied bubble-free by our technicians.
- Drop-Proof & MagSafe Cases: Shock-absorbent military-grade covers, crystal-clear cases, and magnetic wallet folios for all popular models.
- High-Speed Power & Cables: 20W to 65W Power Delivery (PD) wall adapters, braided USB-C and Lightning cables, and magnetic wireless car mounts.
- Camera Lens Armor: Scratch-resistant sapphire glass lens protectors for multi-lens camera systems.
- Cash Buyback Desk (St Marys): Cash on the spot for unwanted, broken, or locked phones if you prefer to trade in rather than repair.
Drive Times & Proximity Catchment
St Marys Workshop (Western Sydney Hub):
• Penrith: 10 mins via Great Western Highway
• Mount Druitt: 6 mins via Carlisle Avenue
• Blacktown: 15 mins via M4 or Great Western Highway
• St Clair & Erskine Park: 7 mins via Bennett Road
Schofields Express (North West Sydney Hub):
• Rouse Hill & The Ponds: 6 to 8 mins via Schofields Road
• Tallawong & Box Hill: 5 to 9 mins via Boundary Road
• Marsden Park: 8 mins via Richmond Road
• Kellyville & Stanhope Gardens: 10 mins
Quick Answer: Where can I find phone repair and screen protectors near me in Sydney & Surrounding Suburbs?
Phone Repair Centre offers same-day walk-in repairs and professional bubble-free screen protector fitting across Sydney. Visit our flagship repair lab at 122 Queen Street, St Marys (near Penrith and Mount Druitt) or our express kiosk at Schofields Village (near Rouse Hill and The Ponds). Most repairs are completed in 30 to 45 minutes with zero data loss and store warranty included.
Frequently Asked Questions & Diagnostic Scenarios
Q: How much does it cost to replace a PS5 HDMI port in Sydney?
Phone Repair Centre charges $139 for same-day reinforced HDMI 2.1 port replacement with a 6-month warranty.
Q: Why does my PS5 have a white light but no picture on TV?
A solid white light proves the console boots, meaning the issue is a damaged HDMI port or video IC. Phone Repair Centre fixes this same-day.
Q: Where can I get PS5 HDMI port repair near St Marys or Schofields?
Visit Phone Repair Centre at 122 Queen Street St Marys (02 8678 3298) or Kiosk 1/227 Railway Terrace Schofields (02 7238 1732).
Decided Not to Repair? Sell It for Instant Cash
If you prefer to upgrade rather than repair, Phone Repair Centre buys damaged, cracked, and unwanted devices for cash on the spot. Our buyback and device trade-in desk is located at our St Marys flagship workshop.
